Tilde Console 1.0

A floating debug console for Godot 4.5+.

• Draggable, resizable, and zoomable interface.
• Extensible API for custom buttons, toggles, and commands.
• Real-time scene inspector and performance monitoring.

  
 Usage 
     
 Built-in Commands 
     
 Developer API 
  

Requirements

• Godot 4.5+

Features

• Multi-Tab Interface: Terminal, Actions, Inspector, and Settings.
• Smart Autocomplete: Context-aware suggestions for commands and arguments.
• Persistent State: Window size, position, alpha, and custom aliases are saved to user://tilde.cfg.
• Live Inspector: Search, browse, and modify the scene tree at runtime (Toggle Visibility, Free Node).
• Dynamic Actions: Instantly create UI for debug variables (Sliders, Toggles, Inputs).
• Watch System: Track variables in real-time within the Actions tab.
• Zoomable UI: Globally scale the console font size with Ctrl + + / -.
• Performance Monitor: Draggable overlay for FPS, RAM, VRAM, and draw calls.

Usage

Setting Up the Plugin

1. Enable the plugin in Project Settings -> Plugins.
2. Make anywhere in the project a file that has "tilde" in it e.g.: tilde_actions.gd
3. Yeah that's basically it.

Basic Controls

• Toggle Console: Press the ~ (Tilde) or ` key.
• Movement: Drag the window by the Title Bar.
• Resizing: Grab any of the edges or corners to resize.
• Scaling: Use Ctrl + + and Ctrl + - to resize all text globally.
• Performance Overlay: Drag the overlay to reposition; click it to cycle text alignment.

Built-in Commands

Developer API

Access the console from any script using the Tilde autoload.

Registering & Modifying Commands

# Simple command
Tilde.register_command("heal", _heal_func, "Heals the player")

# Command with autocomplete suggestions
Tilde.register_command("spawn", _spawn_func, "Spawn item", func(args):
    return ["health_pack", "ammo"]
)

# Rename an existing command
Tilde.rename_command("quit", "exit")

Logging

# Print a message to the console log
Tilde.log_message("changed this and that", Color.GREEN)

Adding Actions (Actions Tab)

Actions provide a quick UI for common tasks.

Tilde.add_category("Combat")

# Simple Button
Tilde.add_button("Kill All", _kill_logic, "Destroy all enemies", true)

# Persistent Toggle (state saved in config)
Tilde.add_toggle("Invincible", false, _toggle_god, "God Mode", "pref_god")

# Number/Text Input
Tilde.add_input("Gold", _set_gold, "Set player currency")

# Dropdown / Option Selection
Tilde.add_dropdown("Map", func(): return ["Forest", "Cave"], _map_logic, "Teleport")

# Sliders & Colors
Tilde.add_slider("Brightness", 0.0, 2.0, _set_bright, 1.0)
Tilde.add_color("Glow", Color.RED, _set_color)

# Organization
Tilde.add_separator()
Tilde.add_spacer(20)

Real-time Monitoring

# Adds a label to the Actions tab that updates every frame
Tilde.add_watch("Player Speed", func(): return player.velocity.length())

Advanced UI Customization

• add_vec2(label, callback, initial): Creates a Vector2 input field.
• add_custom_control(node, filter_text): Inject any Godot Control node into the list.
• set_template_override(type, scene): Override default UI look (e.g., "Button", "Toggle").

Keybind Configuration

• Tilde.keybind(KEY_F1): Adds F1 as an activation key.
• Tilde.set_keybinds([KEY_QUOTELEFT, "ui_cancel"]): Sets multiple keys at once.
• In-Game GUI: Go to the Tilde tab -> Activation Keys to rebind keys in-game (3 slots).

License

Boost Software License 1.0.
