Godot RCON Server

A Source RCON (Remote Console) protocol server implementation for Godot Engine, allowing remote administration and debugging of Godot applications.

Features

• Full RCON Protocol Support: Implements the Source RCON protocol for secure remote access
• Authentication: Password-protected access with per-client authentication
• REPL Commands: Built-in GDScript evaluation and execution capabilities
• Scene Inspection: Browse and inspect nodes in the scene tree remotely
• Performance Monitoring: Access real-time performance metrics
• Multi-client Support: Handle multiple simultaneous RCON connections
• Godot Integration: Works as a Godot addon with autoload singleton

Installation

Method 1: Quick Install (Recommended)

Run this command from your Godot project root directory:

curl -sSL https://raw.githubusercontent.com/mjmorales/godot-rcon/refs/heads/main/install.sh | bash

Or with wget:

wget -qO- https://raw.githubusercontent.com/mjmorales/godot-rcon/refs/heads/main/install.sh | bash

Method 2: Manual Installation

1. Download or clone this repository
2. Copy the addons/godot_rcon folder to your project's addons/ directory
3. Enable the plugin in Project Settings > Plugins > "Godot RCON Server"

Configuration

The RCON server can be configured through code:

# Access the autoloaded RCONServer singleton
var rcon_server = get_node("/root/RCONServer")

# Configure server settings
rcon_server.port = 27015  # Default RCON port
rcon_server.password = "your_secure_password"  # Set empty string for no auth

# Built-in REPL and security (enabled by default)
rcon_server.enable_repl = true  # Use built-in command handler
rcon_server.enforce_dev_security = true  # Block unsafe commands

# Start the server
rcon_server.start()

# Stop the server
rcon_server.stop()

Usage

Starting the Server

func _ready():
    var rcon = get_node("/root/RCONServer")
    rcon.password = "mysecretpassword"
    rcon.port = 27015

    # Connect to signals
    rcon.client_connected.connect(_on_client_connected)
    rcon.client_disconnected.connect(_on_client_disconnected)
    rcon.command_received.connect(_on_command_received)

    # Start server
    if rcon.start() == OK:
        print("RCON server started on port ", rcon.port)

func _on_command_received(command: String, client_id: int):
    var rcon = get_node("/root/RCONServer")

    # Process command using the built-in REPL handler
    var response = REPLCommandHandler.handle_command(command)

    # Send response back to client
    rcon.send_response(client_id, response)

Connecting with RCON Client

You can connect using any Source RCON compatible client:

# Using mcrcon (https://github.com/Tiiffi/mcrcon)
mcrcon -H localhost -P 27015 -p mysecretpassword

# Using rcon-cli (https://github.com/gorcon/rcon-cli)
rcon-cli -a localhost:27015 -p mysecretpassword

Available Commands

The addon includes a REPL command handler with the following built-in commands:

Expression Evaluation

# Direct evaluation (no command prefix needed)
Vector2(10, 20).length()
get_tree().get_nodes_in_group("enemies").size()

# Explicit eval command
eval OS.get_name()

Multi-line Code Execution

exec var player = get_node("/root/Main/Player")
player.health = 100
print("Player healed!")

Node Inspection

# Inspect a specific node
inspect /root/Main/Player

# List all nodes (optional pattern matching)
nodes
nodes Player
nodes Button

Performance Monitoring

# Show available metrics
performance

# Show specific metric
performance fps
performance memory
performance draw_calls

Scene Information

# Show current scene
scene

Help

# Show available commands
help

Security Considerations

• Always use a strong password in production environments
• Consider IP whitelisting at the firewall level
• Disable in release builds unless specifically needed for production monitoring
• The RCON server has full access to the Godot scripting API - treat it as admin access

Built-in Security Features

The addon includes lightweight security features that are enabled by default:

• Dangerous Operation Blocking: Prevents only truly dangerous operations:
  • OS command execution (OS.execute, OS.shell_open, OS.kill)
  • Direct file system access (FileAccess.open, DirAccess.open)
  • Script injection (set_script, source_code, Expression.new())
  • Project settings modification (ProjectSettings.save)
  • Network server creation (HTTP/TCP/UDP/WebSocket servers)
• Output Sanitization: Limits output size and safely formats complex data structures
• Permissive by Default: All other Godot API calls are allowed, including:
  • Node manipulation (queue_free, add_child, etc.)
  • Resource loading (load, preload)
  • Property access and modification
  • Signal connections
  • And much more!

To disable security checks entirely:

rcon_server.enforce_dev_security = false

To enable command logging for debugging:

rcon_server.log_commands = true

API Reference

RCONServer

The main server class, autoloaded as /root/RCONServer.

Properties

• port: int - Server port (default: 27015)
• password: String - Authentication password (empty = no auth)
• running: bool - Server running state (read-only)

Methods

• start() -> Error - Start the RCON server
• stop() - Stop the server and disconnect all clients
• send_response(client_id: int, response_text: String) - Send response to specific client

Signals

• command_received(command: String, client_id: int) - Emitted when a command is received
• client_connected(client_id: int) - Emitted when a client connects
• client_disconnected(client_id: int) - Emitted when a client disconnects

Examples

Custom Command Handler

extends Node

func _ready():
    var rcon = get_node("/root/RCONServer")
    rcon.command_received.connect(_handle_rcon_command)

func _handle_rcon_command(command: String, client_id: int):
    var rcon = get_node("/root/RCONServer")
    var response = ""

    # Custom commands
    if command.begins_with("teleport "):
        var coords = command.split(" ")
        if coords.size() >= 3:
            var x = coords[1].to_float()
            var y = coords[2].to_float()
            get_node("/root/Main/Player").position = Vector2(x, y)
            response = "Player teleported to (%f, %f)" % [x, y]
        else:
            response = "Usage: teleport <x> <y>"
    else:
        # Fallback to built-in REPL handler
        response = REPLCommandHandler.handle_command(command)

    rcon.send_response(client_id, response)

Monitoring Script

extends Node

var rcon: RCONServer

func _ready():
    rcon = get_node("/root/RCONServer")
    rcon.command_received.connect(_on_command)

    # Auto-start server in debug builds
    if OS.is_debug_build():
        rcon.password = OS.get_environment("RCON_PASSWORD")
        if rcon.password.is_empty():
            rcon.password = "debug123"
        rcon.start()

func _on_command(command: String, client_id: int):
    # Log all commands for auditing
    print("[RCON] Client %d: %s" % [client_id, command])

    # Process command
    var response = REPLCommandHandler.handle_command(command)
    rcon.send_response(client_id, response)

Integration with MCP (Model Context Protocol)

I highly recommend this pairing addon with https://github.com/Coding-Solo/godot-mcp and rcon-mcp-server(shameless plug ☺) to enable AI assistants to interact with your Godot application remotely.

Letting LLMs self-verify with access to the Godot runtime and call user code without constant supervision has been an amazing boost in productivity for myself and I encourage everyone to give it a try!

What is MCP?

https://docs.anthropic.com/en/docs/claude-code/mcp

Setup Instructions

1. Start your Godot RCON server (this addon):

   var rcon = get_node("/root/RCONServer")
   rcon.password = "your_secure_password"
   rcon.port = 27015
   rcon.start()


2. Install and configure rcon-mcp-server: ```bash

Install the MCP server

Install the latest version (replace v1.0.0 with desired version)

curl -sSfL https://raw.githubusercontent.com/mjmorales/rcon-mcp-server/main/bin/install.sh | bash -s v1.0.0

Download and review the script

curl -sSfL https://raw.githubusercontent.com/mjmorales/rcon-mcp-server/main/bin/install.sh -o install.sh cat install.sh # Review the script bash install.sh v1.0.0

```

3. Connect through MCP: The AI assistant can now:
   • Create a session to your Godot application
   • Execute GDScript commands remotely
   • Monitor performance metrics
   • Inspect and modify the scene tree
   • Automate testing and debugging tasks

Example Use Cases

• Automated Testing: AI can execute test scenarios and verify game state
• Performance Monitoring: Continuously track FPS, memory usage, and other metrics
• Live Debugging: AI can help diagnose issues by inspecting nodes and executing diagnostic commands
• Content Generation: Dynamically create or modify game objects through AI-driven commands
• Game Balancing: AI can adjust gameplay parameters in real-time based on metrics

Security Note

When using with MCP, ensure you:

• Use strong passwords for RCON authentication
• Run on trusted networks only
• Consider additional firewall rules to restrict access
• Keep the built-in security features enabled (enforce_dev_security = true)

Troubleshooting

Server won't start

• Check if the port is already in use
• Ensure you have network permissions
• Try a different port number

Client can't connect

• Verify the server is running (rcon_server.running)
• Check firewall settings
• Ensure correct password is used
• Try connecting to localhost first

Commands not working

• Check the Godot console for error messages
• Ensure nodes exist at the paths you're trying to access
• Verify your GDScript syntax is correct

License

This addon is provided as-is for use in Godot Engine projects. See LICENSE file for details.

Contributing

Contributions are welcome! Please feel free to submit issues and pull requests.

Credits

Created for the Godot Engine community. RCON protocol implementation based on the Source RCON specification.
