EasyTransition for Godot 4 🎬

EasyTransition is a lightweight screen transition addon for Godot 4 that lets you create smooth, stylized scene changes with a single call. Works as an autoloaded singleton: no setup per scene, no boilerplate.

• ✅ 16 ready-to-use transition animations
• ✅ Customizable transition color
• ✅ Pixel-perfect dithering on the edge of every animation
• ✅ Support for custom mask textures
• ✅ Simple API with native await
• ✅ Parameters adjustable in real time from the editor Inspector

---

✨ Features

• Global access from any script via the EasyTransition singleton
• 16 animations — wipe, radial, diagonal, circular, blur, spiral, curtain, and more
• Mask textures to create transitions with fully custom shapes
• Ordered dithering (Bayer 4×4) with pixel-perfect edges on the transition border
• Per-call transition color configuration
• Manual mode (cover / uncover) for controlled loading screens
• Editor preview: open the autoload scene and tweak shader parameters in the Inspector to see animations in real time

---

📦 Installation (Godot 4)

1) Place the addon in your project

Make sure your project contains this structure:

res://addons/easytransition/
  plugin.cfg
  plugin.gd
  easytransition.tscn
  easytransition.gd
  transition.gdshader

If you cloned the repository, copy or keep the files under res://addons/easytransition/.

2) Enable the plugin

In Godot:

1. Open Project → Project Settings...
2. Go to the Plugins tab
3. Find EasyTransition
4. Click Enable

When enabled, the plugin automatically registers the autoload singleton:

• Name: EasyTransition
• Scene: res://addons/easytransition/easytransition.tscn

From that point you can call EasyTransition from any script in the project.

---

🚀 Basic usage

Simple scene transition

# Black fade, 0.5 s total duration (0.25 s cover + 0.25 s uncover)
EasyTransition.transition_to("res://scenes/game.tscn")

With parameters

await EasyTransition.transition_to(
    "res://scenes/menu.tscn",
    duration          = 0.8,
    animation         = EasyTransition.TransitionAnim.WIPE_RADIAL,
    color             = Color.WHITE,
    dither            = true,
    dither_intensity  = 0.7,
    dither_scale      = 3.0,
)

Use await if you need to run code after the transition completes.

---

📖 API Reference

transition_to()

Covers the screen, changes scene, then uncovers the screen.

EasyTransition.transition_to(
    path:             String,
    duration:         float           = 0.5,
    animation:        TransitionAnim  = TransitionAnim.FADE,
    color:            Color           = Color.BLACK,
    mask_texture:     Texture2D       = null,
    dither:           bool            = false,
    dither_intensity: float           = 0.5,
    dither_scale:     float           = 2.0,
) -> void

Parameter	Type	Default	Description
path	String	—	Path to the destination scene (.tscn)
duration	float	0.5	Total duration in seconds (cover + uncover)
animation	TransitionAnim	FADE	Animation type (see Animations section)
color	Color	BLACK	Screen color during the transition
mask_texture	Texture2D	null	Shape texture for TEXTURE_* animations (see below)
dither	bool	false	Enables pixel-perfect dithered edge
dither_intensity	float	0.5	Dithered edge intensity (0–1)
dither_scale	float	2.0	Size of each pattern cell in screen pixels (1–8)

---

cover()

Covers the screen only (does not change scene). Useful for manual loading screens.

EasyTransition.cover(
    duration:         float           = 0.3,
    animation:        TransitionAnim  = TransitionAnim.FADE,
    color:            Color           = Color.BLACK,
    mask_texture:     Texture2D       = null,
    dither:           bool            = false,
    dither_intensity: float           = 0.5,
    dither_scale:     float           = 2.0,
) -> void

---

uncover()

Uncovers the screen. Always call this after cover().

EasyTransition.uncover(duration: float = 0.3) -> void

---

set_param()

Adjusts a shader parameter at runtime (useful for animations like WAVE or SPIRAL).

EasyTransition.set_param(param: String, value: Variant) -> void

Examples:

EasyTransition.set_param("wave_frequency", 12.0)
EasyTransition.set_param("spiral_tightness", 3.5)
EasyTransition.set_param("wave_amplitude", 0.12)

---

is_transitioning

Read-only property. Returns true while a transition is active. New calls to transition_to() or cover() are ignored while it is true.

if not EasyTransition.is_transitioning:
    EasyTransition.transition_to("res://scenes/game.tscn")

---

🎭 Available animations

All animations are selected via the EasyTransition.TransitionAnim enum.

ID	Name	Description
0	FADE	Smooth alpha fade. With dither enabled it becomes an ordered dissolve (each pixel appears on its Bayer turn).
1	WIPE_LINEAR	Sweeps the screen left to right with a vertical edge.
2	WIPE_RADIAL	Clockwise angular sweep from the right, like clock hands.
3	WIPE_DIAGONAL	Sweeps from the top-left corner to the bottom-right.
4	DUAL_WIPE_LINEAR	Two vertical bars advance from both edges (left and right) and meet in the center.
5	DUAL_WIPE_RADIAL	Two circles grow from the left and right edge centers until they meet in the middle.
6	DUAL_WIPE_DIAGONAL	Top-left and bottom-right corners are covered simultaneously toward the anti-diagonal.
7	BLUR	The scene progressively blurs before fading into the transition color. Requires access to the screen texture.
8	CIRCLE_CENTER_EXPAND	A circle grows from the center of the screen toward the edges.
9	CIRCLE_CENTER_COLLAPSE	Screen edges are covered first and the circle closes toward the center (reverse iris effect).
10	TEXTURE_CENTER_EXPAND	Like Circle Expand but the shape is defined by the texture assigned to mask_texture. White areas of the texture are the last to be covered.
11	TEXTURE_CENTER_COLLAPSE	Inverse of TEXTURE_CENTER_EXPAND. White areas of the texture are covered first.
12	CURTAIN	The screen falls from above like a curtain.
13	WAVE	Like WIPE_LINEAR but with a vertically wavy edge. Configurable with wave_frequency and wave_amplitude.
14	SPIRAL	A multi-arm spiral expands from the center. Configurable with spiral_tightness.
15	TEXTURE_LUMINANCE	Uses any standard greyscale transition texture. Black areas are covered first; white areas last. The most flexible way to create custom transitions.

---

🖼️ Mask textures (mask_texture)

The TEXTURE_CENTER_EXPAND, TEXTURE_CENTER_COLLAPSE, and TEXTURE_LUMINANCE animations use a greyscale texture to define the reveal order:

• Black (0.0) → that pixel is covered at the start of the transition
• White (1.0) → that pixel is covered at the end of the transition
• Mid-grey values create a gradient of coverage order

You can use any black-and-white image: radial gradients, noise, geometric shapes, etc. With dithering enabled, the edge between covered and uncovered areas takes on the characteristic pixel-art look.

var my_mask: Texture2D = preload("res://assets/transitions/star_mask.png")

EasyTransition.transition_to(
    "res://scenes/level2.tscn",
    animation    = EasyTransition.TransitionAnim.TEXTURE_LUMINANCE,
    mask_texture = my_mask,
    dither       = true,
)

Tip: enable Import → Filter on the mask texture for soft edges, or disable it for hard edges. With dithering active, filtering matters less.

---

✏️ Shader parameters

The transition.gdshader shader exposes the following uniforms. You can adjust them from code with set_param() or directly from the Inspector in the editor (see the preview section).

Core parameters

Uniform	Type	Range	Default	Description
animation	int	0–15	0	Index of the active animation
progress	float	0.0–1.0	0.0	Transition progress. 0 = transparent, 1 = screen fully covered
transition_color	vec4	—	(0,0,0,1)	Screen color during the transition

Animation parameters

Uniform	Type	Range	Default	Used by
wave_frequency	float	1.0–20.0	8.0	WAVE — Number of waves along the vertical edge
wave_amplitude	float	0.0–0.3	0.08	WAVE — Wave depth (higher = more curved edges)
spiral_tightness	float	0.5–5.0	2.0	SPIRAL — Number of spiral arms (higher = denser)

Dithering parameters

Uniform	Type	Range	Default	Description
dither_enabled	bool	—	false	Enables the pixel-art dithered edge
dither_intensity	float	0.0–1.0	0.5	Effect intensity. 0 = clean edge, 1 = fully pixelated edge
dither_scale	float	1.0–8.0	2.0	Size of each Bayer pattern cell in screen pixels. Higher values produce a chunkier retro look

---

🎨 Dithering system

The dithering uses a pixel-perfect Bayer 4×4 matrix to create a pixel-art style edge on every transition animation.

How it works:

Instead of a smooth anti-aliased edge, each Bayer pattern cell decides whether the pixel in the transition zone should appear covered or uncovered. This creates the characteristic pixelated border of retro games.

dither_scale	Visual result
1.0	Individual pixel-level pattern (subtle grain)
2.0	2×2 px cells (balanced retro look)
4.0	4×4 px cells (chunky, very blocky look)
8.0	Very large cells, strong effect

The system guarantees that:

• At progress = 0.0 → no pixel is covered, regardless of the pattern
• At progress = 1.0 → every pixel is covered, with no residual gaps
• Between 0 and 1 → the pixelated edge progresses continuously without any abrupt jumps

---

🧪 Editor preview

You can test all animations and settings directly in the Godot editor without running the game:

1. Open res://addons/easytransition/easytransition.tscn in the editor
2. Select the ColorRect node in the scene tree
3. In the Inspector, expand the ShaderMaterial → Shader Parameters section
4. Adjust the progress parameter to see the transition advance
5. Change animation to try different types
6. Enable dither_enabled and adjust dither_scale to see the pixelated effect
7. Modify wave_frequency, spiral_tightness, or other animation parameters in real time

This is especially useful for calibrating dither_scale, wave_frequency, and spiral_tightness before using them in your project.

---

💡 Practical examples

Simple fade (black)

EasyTransition.transition_to("res://scenes/game.tscn")

White wipe with chunky dithering

EasyTransition.transition_to(
    "res://scenes/level_2.tscn",
    duration          = 1.0,
    animation         = EasyTransition.TransitionAnim.WIPE_LINEAR,
    color             = Color.WHITE,
    dither            = true,
    dither_intensity  = 1.0,
    dither_scale      = 4.0,
)

Tuned spiral

EasyTransition.set_param("spiral_tightness", 4.0)

await EasyTransition.transition_to(
    "res://scenes/boss.tscn",
    duration  = 1.2,
    animation = EasyTransition.TransitionAnim.SPIRAL,
    color     = Color(0.1, 0.0, 0.05),
)

Manual loading screen

# 1. Cover the screen
await EasyTransition.cover(
    0.4,
    EasyTransition.TransitionAnim.CIRCLE_CENTER_EXPAND,
    Color.BLACK,
)

# 2. Load resources while the screen is covered
ResourceLoader.load_threaded_request("res://assets/world.tscn")
while ResourceLoader.load_threaded_get_status("res://assets/world.tscn") != ResourceLoader.THREAD_LOAD_LOADED:
    await get_tree().process_frame

# 3. Switch to the new scene
get_tree().change_scene_to_packed(ResourceLoader.load_threaded_get("res://assets/world.tscn"))

# 4. Uncover the screen
await EasyTransition.uncover(0.4)

Transition with a custom texture

var mask := preload("res://assets/masks/star.png") as Texture2D

await EasyTransition.transition_to(
    "res://scenes/menu.tscn",
    duration     = 0.9,
    animation    = EasyTransition.TransitionAnim.TEXTURE_LUMINANCE,
    color        = Color(0.05, 0.05, 0.1),
    mask_texture = mask,
    dither       = true,
    dither_scale = 2.0,
)

---

🧩 Addon components

File	Description
plugin.gd	Registers and removes the autoload when the plugin is enabled/disabled. On enable, verifies the scene has the shader assigned.
easytransition.tscn	Autoload scene. Contains a CanvasLayer (layer 128) with a fullscreen ColorRect.
easytransition.gd	Main logic: tween management, public API, and shader configuration.
transition.gdshader	canvas_item shader with 16 animations, mask texture support, and a Bayer 4×4 dithering system.

---

⚙️ How it works internally

1. When transition_to() is called, the singleton configures the shader parameters and starts a Tween that animates progress from 0.0 → 1.0 (cover phase).
2. When the Tween finishes, get_tree().change_scene_to_file() is called.
3. A second Tween immediately animates progress from 1.0 → 0.0 (uncover phase).
4. The CanvasLayer at layer 128 ensures the ColorRect renders above every element in the active scene, including other CanvasLayer nodes.
5. process_mode = PROCESS_MODE_ALWAYS ensures the transition is not interrupted if the scene tree is paused.

---

🛠️ Notes

• Designed for Godot 4.
• The singleton is named EasyTransition and is accessible from any script without preload.
• Multiple calls to transition_to() or cover() while is_transitioning == true are automatically ignored.
• For the BLUR effect the ColorRect samples the screen buffer; make sure the node renders after the scene (the CanvasLayer 128 guarantees this).
• Mask textures for TEXTURE_LUMINANCE should be imported with Compress Mode: Lossless to preserve exact luminance values.

---

📄 License

MIT License © 2026 IUX Games, Isaackiux.
