LLM Chatbot Plugin for Godot 4

A modular, provider-agnostic plugin for adding LLM-powered chatbots to any Godot 4 project. Drop in a chat UI, connect your API key, describe your character... done!

---

Features

• Waterfall fallback — configure multiple providers; the plugin tries them in order until one succeeds.
• Built-in providers — Portkey (gateway/router) and Google AI Studio (Gemini) included out of the box.
• Extensible — add any REST-based LLM by extending LLMProvider.
• Game-event triggers — fire AI responses from code without player input.
• Typewriter effect — optional character-by-character reveal with skip support.
• Question cap — limit how many times a player can query the AI per session.
• Character sprite — swap textures between "neutral" and "talking" states automatically.
• Conversation logging — a signal fires with the transcript batch after every response.

---

File Structure

addons/llm_chatbot/
├── plugin.cfg                   # Plugin manifest
├── plugin.gd                    # Registers the LLMManager autoload
├── autoload/
│   └── LLMManager.gd            # Singleton — send queries, get responses
├── providers/
│   ├── LLMProvider.gd           # Abstract base class
│   ├── PortkeyProvider.gd       # Portkey AI gateway
│   └── GoogleAIProvider.gd      # Google AI Studio (Gemini)
├── ui/
│   └── ChatController.gd        # Drop-in chat UI controller node
└── LLMSetup.example.gd          # Copy into your project to configure keys

---

Installation

1. Copy the addons/llm_chatbot/ folder into your project's addons/ directory. (if the addons folder does not yet exist, manually add it inside of the res:// folder in your project)
2. Open Project → Project Settings → Plugins and enable LLM Chatbot.
   This automatically registers LLMManager as a global autoload.
3. Copy LLMSetup.example.gd somewhere in your project (e.g. res://autoloads/LLMSetup.gd), add it as an Autoload (below LLMManager in the list), and fill in your API keys.

⚠️ Never commit API keys to version control. Use a .env file, Godot's ProjectSettings with a user-override file, or a secrets manager.

---

Quick Start

1. Configure providers

# LLMSetup.gd (Autoload)
extends Node

func _ready() -> void:
    var portkey := PortkeyProvider.new()
    portkey.api_key = "pk-..."
    portkey.model   = "@openrouter/google/gemini-2.0-flash-lite"
    LLMManager.add_provider(portkey)

    var google := GoogleAIProvider.new()
    google.api_key = "AIza..."
    google.model   = "gemini-2.0-flash-lite"
    LLMManager.add_provider(google)   # fallback

2. Add a ChatController to your scene

1. Create a scene with your chat UI (LineEdit, Button, Label).
2. Add a Control node with the script addons/llm_chatbot/ui/ChatController.gd.
3. In the Inspector, assign:
   • Input Field Path → your LineEdit
   • Send Button Path → your Button
   • Response Label Path → your Label or RichTextLabel
   • System Prompt → your character's identity and rules
   • Ai Speaker Name → e.g. "Erwin" (used in conversation history)

That's it — the controller wires everything up automatically in _ready().

---

Inspector Reference

Required UI Nodes

Export	Type	Description
input_field_path	NodePath	The player's text input (LineEdit)
send_button_path	NodePath	The submit button
response_label_path	NodePath	Where AI responses are displayed

Optional UI Nodes

Export	Type	Description
char_count_label_path	NodePath	Shows current / max character count

AI Persona

Export	Default	Description
system_prompt	"You are a helpful assistant..."	Prepended to every query
ai_speaker_name	"AI"	AI label in conversation history
player_speaker_name	"Player"	Player label in conversation history
thinking_text	"Thinking..."	Shown while waiting for a response
send_button_active_label	"Send"	Button text after the first message

Typewriter Effect

Export	Default	Description
use_typewriter_effect	true	Animate text character by character
allow_skipping	true	Click anywhere to skip the animation
typing_speed	30.0	Characters revealed per second

Input Limits

Export	Default	Description
char_limit	280	Max input length. 0 = unlimited
max_questions	0	Max queries per session. 0 = unlimited
question_limit_prompt_suffix	(see script)	Appended to the prompt when cap is hit

Character Sprite

Export	Type	Description
character_sprite	Sprite2D	Sprite to animate. Leave blank to disable
character_textures	Dictionary	Keys: "neutral", "talking" (plus any custom keys)

# Example — set in code instead of Inspector
$ChatController.character_textures = {
    "neutral": preload("res://art/guide_idle.png"),
    "talking": preload("res://art/guide_talk.png"),
}

---

Signals

ChatController

signal ai_responded(text: String)
signal conversation_saved(log_entries: Array)
signal question_limit_reached()

LLMManager

signal response_received(text: String)
signal all_providers_failed(last_error: String)

---

Triggering from Game Code

# Trigger a chat response when something happens in the game world
$ChatController.trigger_event(
    "Player picked up the rusty key",
    "React with mild surprise and hint at what it might unlock."
)

# Or send a message directly (bypasses the UI input field)
$ChatController.send_message("What should I do next?")

# Reset for a new playthrough / scene
$ChatController.reset_conversation()

---

Conversation Logging

Every time the AI responds, ChatController emits conversation_saved with the batch of new lines as an Array[String]. Connect this signal to write logs however you like:

$ChatController.conversation_saved.connect(_on_log_ready)

func _on_log_ready(entries: Array) -> void:
    var text := " | ".join(entries)
    # Write to a file, send to your backend, call an Autoload, etc.
    FileAccess.open("user://chat_log.txt", FileAccess.WRITE).store_string(text)

---

Adding a Custom Provider

1. Create MyProvider.gd anywhere in your project:

class_name MyProvider
extends LLMProvider

var api_key: String = ""

func _init() -> void:
    provider_name = "MyService"

func send_request(parent_node: Node, prompt: String) -> void:
    var http := HTTPRequest.new()
    parent_node.add_child(http)

    var headers := ["Authorization: Bearer " + api_key, "Content-Type: application/json"]
    var body := JSON.stringify({"prompt": prompt})

    http.request_completed.connect(_on_done.bind(http))
    http.request("https://api.myservice.com/generate", headers, HTTPClient.METHOD_POST, body)

func _on_done(_r, code, _h, body, http):
    http.queue_free()
    var json := _parse_json(body)
    if code == 200:
        response_received.emit(json["text"])
    else:
        request_failed.emit("HTTP " + str(code))

2. Register it:

var my = MyProvider.new()
my.api_key = "..."
LLMManager.add_provider(my)

---

Security Notes

• Keep API keys out of version control. Use a .gitignored config file or Godot's user:// path to load them at runtime.
• The question_limit_prompt_suffix injection mitigates prompt-injection from the player trying to override the character's persona, but it is not a security boundary — do not rely on it alone for sensitive applications.
