JoltPhysics3DJoint RobotArm Godot4.6

A high-performance robotics simulation project for Godot 4.6, utilizing the native Jolt Physics engine. This project implements industrial-grade joint control by transitioning from basic hinges to a sophisticated 6-DOF Servo Control model, providing a robust foundation for researchers and hobbyists interested in realistic 3D kinematics.

📖 Introduction

This project features a 5-axis robotic arm fully simulated within Godot 4.6. By leveraging the advanced capabilities of Jolt Physics, it achieves high-fidelity motion that eliminates common simulation artifacts like "joint jitter" or "spongy constraints."

This work is a modern refactor and upgrade of the Enhanced HingeJoint3D project by jdarc, specifically optimized for the 2026 high-performance simulation standards.

✨ Features

• 5-Axis Independent Control: Precision management of Base, Arm, Wrist, and dual Claw components.
• High-Fidelity Joint Simulation: Uses Generic6DOFJoint3D to ensure rigid mechanical connections and prevent stretching under load.
• Real-time Visual Feedback: A clean UI dashboard with interactive progress bars for live angle monitoring.
• Safety Constraints: Integrated soft and hard limits (-90° to 90°) to prevent mechanical self-intersection.
• Advanced Servo Logic: Combines spring stiffness with motor velocity for smooth, weighted movements.

🛠 Core Methodology & Optimizations

1. From Hinge to 6-DOF

Unlike standard hinge joints, this project utilizes Generic 6-Degrees-of-Freedom (6-DOF) joints. This configuration allows for the absolute locking of all three linear translation axes, ensuring that arm segments remain perfectly attached even during high-speed rotations.

2. Spring-Position Servo Control

The project moves away from simple velocity motors in favor of a Position Servo Model:

• Targeting: The Equilibrium Point of the angular spring serves as the "Target Angle."
• Damping: High damping values are applied to absorb high-frequency oscillations (eliminating the "jelly effect").
• Force Limiting: Motors provide the necessary torque to overcome gravity, while the spring ensures precise alignment.

3. Local Coordinate Angle Extraction

A common issue in robotics simulation is "Linkage Contamination," where moving a parent joint affects the reading of a child joint. This project solves this using Affine Inverse Transformation.

• Method: By calculating the transform of the child body relative to the joint's own basis, the system extracts a pure local angle.
• Result: Every UI reading is 100% accurate relative to its specific pivot, regardless of the arm's global posture.

4. Jolt Physics Tuning

• Solver Iterations: Optimized to 64 for stable mechanical constraints.
• ERP Optimization: Native Jolt property mapping is used to bypass legacy Godot Physics parameter warnings.

🚀 Usage Guide

1. Setup

Download the repository files to your local directory and open the project using Godot 4.6 or later. Ensure the Godot Jolt physical engine is enabled in your Project Settings.

2. Running the Scene

Open the file example.tscn and press F5 to run.

3. Key Mappings

4. UI Dashboard

• Progress Bars: Represent the current rotation relative to the full mechanical range (-180° to 180°).
• Degree Labels: Display the specific physical angle extracted from the Jolt engine, accurate to 0.1°.

🔗 Credits & References

• Original Project: Enhanced HingeJoint3D by jdarc.
• Physics Engine: Godot Jolt.

📄 License

This project is released as open-source. When using this for secondary development, please provide credit to the original contributors.
