GDExtension FSM Architecture

A high-performance, reusable Finite State Machine (FSM) architecture for Godot using GDExtension (C++) and GDScript.

---

Overview

This system is designed to combine:

• C++ performance for core systems such as state management, memory handling, and execution flow
• GDScript flexibility for fast and intuitive gameplay logic

The architecture follows a simple flat hierarchy consisting of:

• A single Controller node
• Multiple State nodes as its children

This design keeps the system easy to use, scalable, and efficient.

---

Architecture Summary

Component	Responsibility
NodeState	Base class for all states
NodeStateController	Manages state transitions and execution

---

Core Concepts

• Only one state is active at a time
• All states are direct children of the controller
• State transitions are handled using signals
• State lookup is optimized internally for fast switching

---

Core Classes

NodeState

The base class that all states extend.

• Acts as the interface between the engine and your gameplay logic
• Designed to be extended in GDScript
• Provides lifecycle hooks for entering, exiting, and updating states

Each state is responsible only for its own behavior.

---

NodeStateController

The central manager of the FSM.

• Keeps track of all available states
• Controls which state is currently active
• Handles transitions between states
• Ensures only the active state is updated

---

Developer Workflow

1. Scene Setup

• Add a NodeStateController to your entity (player, enemy, etc.)

---

2. Create States

• Add child Node nodes under the controller
• Attach scripts that extend NodeState

Example state names:

• Idle
• Walk
• Jump

---

3. Assign Initial State

• Select the controller node
• Assign the initial state using the Inspector

---

4. Implement State Logic

Example:

extends NodeState

func _on_physics_process(delta):
    if Input.is_action_pressed("move"):
        move_character(delta)
    else:
        transition.emit(&"idle")

States emit a transition signal to request a change. The controller handles the switch automatically.

---

Performance Design

• Only the active state is processed at runtime
• No unnecessary updates on inactive states
• Fast state switching through internal caching
• Designed to scale efficiently for complex behaviors

---

Build System (SCons)

The project uses SCons for building the GDExtension.

Platform Support

This system supports all platforms that Godot supports, including:

• Windows
• Linux
• macOS
• Android
• iOS
• Web

---

Future Expansion

The current implementation is a flat FSM, but it is designed to support future expansion into hierarchical state machines.

This would allow:

• State machines inside other state machines
• More complex and modular behavior systems

Example structure:

Player FSM
 └── Combat State (Controller)
      ├── Attack
      ├── Defend

---

Key Benefits

• Clean and simple setup in the Godot editor
• Clear separation between engine logic and gameplay logic
• High performance through native code
• Fast iteration using GDScript
• Scalable design for larger projects

---

Performance Benchmark

Because Node State Controller is written entirely in C++ as a GDExtension, it handles state caching, Dictionary lookups, and virtual method execution with zero script-level overhead.

You can take a look at the C++ implementation in src/ and GDScript implementation in fsm-demo/scripts/gd_state_machine/ and a look at the benchmark script in fsm-demo/benchmark

Benchmark running continuous 100000 state transitions:

Implementation	Time Taken (ms)	Speed Increase
Pure GDScript FSM	179.33	1.0x (Baseline)
C++ Node State Controller	90.91	1.97x Faster

(Tested on Godot 4.x - Windows 11 - Ryzen 5 9600X 6 Cores 12 Threads)

---

License

This project is licensed under the MIT License.

---

Contribution

Contributions, improvements, and extensions are welcome.

---

Credits

• Huge thanks to
  • ErisEsra's character template. You can check out the assest here.
  • Kenney NL for monochrome tilemap. You can check out the asset here.
• If you can then please donate to the artists who can make projects like this possible.

---

Summary

This FSM architecture provides a strong foundation for building responsive and maintainable gameplay systems in Godot by combining:

• Native execution speed
• Script-level flexibility
• A clean and intuitive structure

---
