Godot State Provider

A Godot 4 addon that implements a Provider/Consumer pattern for state management. It lets you define state machines as gdscript classes and inject them into your scene tree (no singletons required).

Requirements

• Godot 4.6+

Core Concepts

Value

Value is the base class for everything state related. Each subclass has a unique type identifier derived from its script name, which is used to locate the matching provider in the scene tree.

State

State extends Value and adds two lifecycle hooks:

func _on_enter() -> void: pass
func _on_exit() -> void: pass

StateMachine

StateMachine holds the current State and emits state_changed when the state transitions. It validates that only compatible state types are accepted and calls _on_exit / _on_enter automatically. Processors are a special type of state machine that also forward _physics_process, _process, and _draw to the active state's hooks, explained in the StateProcessor section.

Nodes

Providers

Providers instantiate a Value and make it available to all descendant nodes. They can be used directly in the scene tree without subclassing. Set the exported script property and add the node.

Provider

Set the value_script export to any Value subclass. When a consumer lower in the tree requests that type, it will receive the instance this node holds.

RootNode
  └── Provider (value_script = MyStateMachine)
        └── ... (any descendant can consume this)

StateProvider

A Provider specialised for StateMachine subclasses. Prefer this over the raw Provider when providing state machines, as it ensures the value is initialised as a StateMachine.

MultiProvider / StateMultiProvider

Accepts an array of scripts and automatically nests a Provider (or StateProvider) for each one, so a single node can provide multiple values to its children.

StateMultiProvider (scripts = [PlayerStateMachine, InventoryStateMachine])
  └── (children can consume both state machines independently)

Consumers

Consumers walk up the scene tree to find the nearest Provider ancestor matching a given type and return its value. Unlike providers, consumers are not useful on their own you should extend them and override their hooks to add behaviour.

Consumer

The base consumer. For a quick setup just override default_script_factory and return the type of value you require from a provider, then call get_value() to retrieve it. For more complex use cases, override _init.

class_name MyConsumer extends Consumer

func default_script_factory() -> Script:
    return CustomValue

func do_something() -> void:
    var value: CustomValue = get_value()

StateConsumer

A Consumer specialised for StateMachine values. Extend this when you need access to a state machine.

StateListener

A Consumer that automatically connects to the state machine's state_changed signal. Extend it and override _on_state_changed to react to state transitions.

class_name NavigationListener extends StateListener

func _init() -> void:
    super._init(func() -> Script: return NavigationStateMachine)

func _on_state_changed(state: State) -> void:
    if state.is_type(NavigationState.Menu):
        # load menu scene

Processor

ProcessorState / ProcessorStateMachine

ProcessorState extends State with _physics_process, _process, and _draw hooks that receive a reference to the processor node. ProcessorStateMachine delegates these calls to the active state.

class_name PlayerStateMachine extends ProcessorStateMachine

func _physics_process(delta: float, processor: PlayerProcessor) -> void:
    if Input.get_vector("move_left", "move_right", "move_up", "move_down") != Vector2.ZERO:
        set_state(PlayerState.Move.new())
    super._physics_process(delta, processor)

class_name PlayerState extends ProcessorState

class Move extends PlayerState:
    func _physics_process(_delta: float, _processor: PlayerProcessor) -> void:
        var direction = Input.get_vector("move_left", "move_right", "move_up", "move_down")
        _processor.player.velocity = direction * _processor.SPEED
        _processor.player.move_and_slide()

StateProcessor

A Consumer whose _physics_process, _process, and _draw are forwarded to the active ProcessorState. Extend it and use the _state_physics_process, _state_process, and _state_draw callbacks to run logic on the processor node from within a state, or put the logic directly on the state class itself. Example provided in the included example project.

class_name PlayerProcessor extends StateProcessor

func _init() -> void:
    _value_container = ValueContainer.new(PlayerStateMachine.new())

Example

The included example (example/) demonstrates two patterns:

Navigation - A StateProvider holds a NavigationStateMachine. A StateListener subclass reacts to navigation state changes and swaps scenes.

Player - A StateProcessor subclass drives a PlayerStateMachine. Movement logic lives inside the PlayerState.Move class and receives the processor as context, keeping state logic self contained.

License

See LICENSE.txt.
