OBJExporter Plugin for Godot 4.x

Godot plugin to export and import meshes as OBJ (.obj, .mtl) from games and apps during runtime. Does not use any editor-only classes, and is pure GDScript (not requiring mono version nor any GDExtension shenanigans).

Based on the work of mohammedzero43's CGSExporter and fractilegames's godot-obj-export for the exporter, and includes a wrapper method for the ObjParse class from Ezcha's gd-obj for importing.

How To Export Meshes

Install the plugin, activate it. This will make the OBJExporter singleton available to your game/app.

To save a mesh to a .obj/.mtl file pair, call:

OBJExporter.save_mesh_to_files(mesh, file_path, file_name_without_extension)

So if you want to save the mesh in a my_meshinstance3d node into user://model/my_file.obj and user://model/my_file.mtl, use:

OBJExporter.save_mesh_to_files($my_meshinstance3d.mesh, "user://model/", "my_file")

Important: the file_path must exist, so check and create it with DirAccess first, if needed.

Signals

Depending on model complexity, the file generation might take a good while, so it happens asynchronously. Does not use threads, instead it relies on await to run in the background in the main thread.

Therefore, the OBJExporter singleton has 3 signals to inform your application:

• export_started:

Emitted when save_mesh_to_files() is called

• export_progress_updated(surf_idx, progress_value):

Emitted periodically during file generation (every 60 vertices), to be used to update progress bars and similar. Arguments are surface index (starting at 0) and a normalized progress value (that is, range from 0.0 to 1.0) of that surface. There is no argument for overall progress value as calculating this would be unnecessarily costly.

• export_completed(object_file, material_file):

Emitted when the process is completed and the files are saved to disk. The arguments are the final filenames used (e.g. user://model/my_file.obj and user://model/my_file.mtl), composed from the input arguments.

Since OBJExporter is a singleton and therefore not visible in your scene tree in the editor, connect these signals via code (if used), e.g.:

func _ready():
    OBJExporter.export_started.connect(_on_export_started)
    OBJExporter.export_completed.connect(_on_export_completed)
    OBJExporter.export_progress_updated.connect(_on_export_progress)

How To Import Meshes

To import a mesh from an .obj file autodetecting the .mtl file, call:

OBJExporter.load_mesh_from_file(file_path)

Or you can also manually specify the material file:

OBJExporter.load_mesh_from_file(obj_file_path, mtl_file_path)

This method is fully synchronous and will return the mesh (it is a transparent call to ObjParse.load_obj).

Included Example Project

Included in the repo is an example project which exports the built-in mesh from a MeshInstance3D node.

The exported .obj/.mtl, later imported into Blender:

Clicking Import Suzanne will do exactly what it says on the tin:

Thanks to bananu7 for pointing me in the right direction on indexing vertices with SurfaceTool.
