Godot-DragonBones Plugin

点击查看中文说明。

A GDExtension plugin to add DragonBones for Godot.

Links

• Godot: https://godotengine.org
• DragonBones: http://dragonbones.com
• A simple demo from @blurymind: https://github.com/blurymind/godot4-dragonbones-demo-animations-and-slots/tree/main.

Support Versions

• Godot 4.2 +
• DragonBones Pro 5.6

Get plugin

1. Download from release page.
2. Download from Assets Library.
3. Clone this repo and compile by yourself.

How to compile

1. Clone this repo with submodules.

2. Ensure you have "python", "Scons", and a appropriate c++ compiler.

3. Navigate to the root of local repo, run compile command, for example: For debug:

   scons target=template_debug debug_symbols=yes


   For release:

   scons target=template_release


   Please refer the build system system of godot-cpp for more compile options.

4. If compiling is successfully, you can get the compiled plugin in demo/addons/godot_dragon_bones.daylily-zeleen.

Run "demo" project

The "master" branch has not contains compiled libraries, "demo" project can't be run correctly if you clone this branch or download it as zip archive and run it directly!

To run "demo" project, here have 3 way:

1. Compile this plugin by following the previous part that "How to compile".
2. Download appropriate archive from release page, and plug it into "demo" project.
3. Open "demo" project directly, ignore errors and warnings, goto "Asset Library", use "Godot-DragonBones" as keyword to search this plugin and install it, than reboot the editor.

Export

1. Web: "Extensions Support" is required; "Thread Support" is requred if you use the precompiled plugin.

Contents

This repository is improved from gddragonbones.

1. Change to GDExtension for Godot 4.x.
2. Implement a import plugin to import DragonBones files automatically.
3. Imported Resource is DragonBonesFactory :
   1. One factory can contain multi DragonBones data and Atlas data files.
   2. Can select DragonBones data and skin which are in factory to instantiate in DragonBones node.
   3. If detect DragonBones assets (for example, xxx_ske.json/dbbin and xxx_tex.json) in editor, it will generate a factory resource(xxx_ske.dbfactory) at the same folder (this is disabled by default, you can turn it on in project settings by setting Godot Dragon Bones/auto_generate_dbfactory to true).
4. DragonBonesArmatureView node:
   • The display node of DragonBones armature.
   • You can get its DragonBonesArmature instance by get_armature().
5. DragonBonesArmature node:
   • Instantiated by DragonBonesArmatureView node which according to DragonBonesFactory, don't instantiate it by yourself.
   • Don't free by yourself, it will lead to crash!!
   • In editor, a proxy property in DragonBonesArmatureView node, which it's type is DragonBonesArmatureProxy, name is "armature", will be indicated as the DragonBonesArmature node. If the armature have child armatures, it will have a "sub_armatures" property in DragonBonesArmatureProxy.
6. DragonBonesArmatureProxy is editor use only!! Don't instantiate by yourself, and don't access relevant objects/properties, They are unavailable in release build.
7. Can access DragonBonesSlot and DragonBonesBone to do some advance operations through DragonBonesArmature (but this is lack of test.).
8. I have not time to write a further description, please refer source code in "src/" for more details.

Others

If this plugin can help you, please consider to buy me a coffee.

I'm not familiar with DragonBones, so there maybe have some wrong concepts in my code. This repo is create for my personal project, and it is useful enough, so I think I will not do more optimize anymore. Of course, if I encounter bug, I will try to fix it. If you have any improvement/repair, welcome to commit your pull request.
